1.Images sensor(optional)

  1/4"  PV3109: 1288*728. fisheye lens, Angle:160°, Minimum illumination:0.2 lux

2.TV system: PAL/ NTSC (Default NTSC)

3.Work voltage: DC12V (12-24V for option) , DCDC Buck module on tail cable, Current: <100ma

4.metal shell, waterproof: IP69K

5.white wire: mirrored//original switch; green wire:guide line switch. Default: Mirrored/Guide line

Accessories:Camera(Drilling & bracket installation)+Manual+6M video cable+BMW to RCA cable+screws+drill

White wire:mirrored / original switch，Green wire: for switch guide line
